SIMATIC HMI TP400 Basic Keyless | 4" Touch Basic Panel, PROFINET, Neutral Design

SIMATIC HMI TP400 Basic Keyless | 4" Touch Basic Panel, PROFINET, Neutral Design About

The Siemens 6AV2143-6DB00-0AA0 is a compact SIMATIC HMI TP400 Basic Keyless operator panel designed for entry-level machine operation, monitoring, and visualization applications. It features a 4-inch TFT color touchscreen with 480 272 pixel resolution and 65,536 colors, providing clear process and machine visualization without physical function keys. The panel supports intuitive touch operation and is equipped with an ARM processor, 10 MB user memory, and a real-time clock. Communication is provided through 1 Industrial Ethernet/PROFINET interface, with support for TCP/IP-based communication and compatible industrial controllers. It also includes 1 USB interface for service and data handling. The unit operates from a 24 V DC power supply and provides IP65 protection at the front, making it suitable for installation in industrial control cabinets and machine panels. With approximate front dimensions of 140 116 mm, a mounting depth of around 52 mm, and a net weight of approximately 0.462 kg, the 6AV2143-6DB00-0AA0 is well suited for compact machines, packaging equipment, conveyor systems, pump control, and basic automation applications. It is configurable using WinCC Basic V13 / STEP 7 Basic V13 or later compatible engineering software.
