SIMATIC ITC1500 V3 PRO | 15" Support-Arm Multi-Touch Industrial Thin Client

SIMATIC ITC1500 V3 PRO | 15" Support-Arm Multi-Touch Industrial Thin Client About

The Siemens 6AV6646-1BD15-0AA0 is a SIMATIC ITC1500 V3 PRO Industrial Thin Client designed for decentralized visualization and operator control in industrial automation environments. It features a 15.6-inch widescreen TFT display with 1366 768 pixel resolution, 16.7 million colors, and dimmable LED backlighting with an estimated 50,000-hour backlight life at 25 C. The non-reflective, tempered mineral-glass screen uses projected-capacitive multi-touch technology and includes an on-screen monitor keyboard for intuitive operation.

This version is specifically configured for support-arm mounting with a round-tube, extendable design, allowing additional expansion elements to be integrated into the installation. It supports RDP, VNC, SmartServer, HTML5, and other remote visualization protocols, while the display can be separated from the computer unit by up to 100 m. The unit operates from a 24 V DC supply, with an allowable range of 19.228.8 V DC. It provides 2 Industrial Ethernet interfaces with integrated switch functionality and 4 USB interfaces for peripherals.
