SIMATIC HMI TP1500 Comfort Pro 15" Support Arm Touch Panel, Expandable, Round Pipe

About SIMATIC HMI TP1500 Comfort Pro 15" Support Arm Touch Panel, Expandable, Round Pipe

The Siemens 6AV2124-0QC24-0BX0 is a premium 15.4-inch widescreen HMI panel precision-engineered for cabinet-free, direct machine-level integration on the factory floor. Part of the specialized SIMATIC HMI TP1500 Comfort Pro series, this rugged operator terminal is explicitly designed for support arm installation utilizing an expandable, round-pipe mounting layout that accommodates additional extension units. It features a brilliant TFT touch display with a sharp 1366 x 768 pixel resolution and 16 million colors to provide operators with fluent, responsive visualization across intricate automated machinery workflows. For comprehensive industrial networking, the unit integrates high-speed PROFINET Ethernet interfaces alongside a legacy MPI/PROFIBUS DP port to handle real-time data communication across diverse PLC networks. The robust, fully enclosed all-round design allows the terminal to successfully withstand harsh plant environments without requiring an additional control cabinet enclosure. Running a stable Windows Embedded Compact 2013 (WEC 2013) platform backed by an expanded 24 MB configuration memory, it efficiently coordinates intensive local data tracking, multi-variable recipes, and complex diagnostic scripts. The entire layout is seamlessly programmed using WinCC Comfort software from version V14 SP1 with HSP onward.
