Siemens, SIMATIC S7-300, 6ES7317-2EK14-0AB0, 0 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens, SIMATIC S7-300, 6ES7317-2EK14-0AB0, 0 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC. Specification

Protection Level
IP20

Rated Voltage
24 V DC Volt (V)

Phase
N/A (Direct Current infrastructure alignment)

Efficiency
~4.65 W Typical Power Loss / Heat Dissipation

Operating Temperature
0 C to +60 C Celsius (oC)

Mounting Type
S7-300 Rail Profile Mounting

Humidity
Max. 95% relative humidity (Non-condensing)

Input Current
Max. 750 mA from 24V DC / Inrush current peaks at 4.0 A

Usage
Industrial Automation

Main Material

Condition
New

Size
4.0 cm Overall Width

Function
Dual Comms: 1st Interface MPI/DP (12 Mbit/s) | 2nd Interface Industrial Ethernet PROFINET

Height
12.5 Centimeter (cm)

Application
Demanding plants requiring large program memory, fast processing, and networking

Product Type
SIMATIC S7-300 High-Performance PROFINET CPU

Weight
0.34 Kilograms (kg)

Dimension (L*W*H)
13.0 cm x 4.0 cm x 12.5 cm Centimeter (cm)

Color
Industrial Gray

Power Mode
Other

Voltage
24 V DC Volt (v)

Width
4.0 Centimeter (cm)

Length
13.0 Centimeter (cm)

Power Consumption
4.65 Watt (W)

Accessories
Micro Memory Card (MMC) required for operation (Ordered Separately)

Warranty
Standard Siemens Factory Warranty

Siemens, SIMATIC S7-300, 6ES7317-2EK14-0AB0, 0 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC. Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About Siemens, SIMATIC S7-300, 6ES7317-2EK14-0AB0, 0 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

The Siemens SIMATIC S7-300 CPU 317-2 PN/DP central processing unit (model number 6ES7317-2EK14-0AB0) is a high-performance modular controller engineered for demanding applications with large quantity frameworks, featuring 0 integrated digital outputs (DO), 0 digital inputs (DI), 0 analog outputs (AO), and 0 analog inputs (AI). It depends entirely on external backplane signal modules or decentralized nodes to manage plant I/O telemetry.

Operating on a single-phase control arrangement backed by a standard 24 V DC voltage supply, this processor features a generous 1 MB integrated work memory and requires a SIMATIC Micro Memory Card (MMC) for program execution. The CPU is built with two integrated communication interfaces: a combined MPI/PROFIBUS DP master/slave port (up to 12 Mbit/s) and an Industrial Ethernet PROFINET interface with an integrated 2-port switch. This dual networking architecture enables rapid peer-to-peer data transfers, flexible component grouping, and seamless enterprise integration.
