Siemens, SIMATIC S7-1200, 6ES7231-5QA30-0XB0, 0 DO, 0 DI, 0 AO, 1 AI, Single-phase, 24 V DC.

Price 30000.0 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

Siemens, SIMATIC S7-1200, 6ES7231-5QA30-0XB0, 0 DO, 0 DI, 0 AO, 1 AI, Single-phase, 24 V DC. Specification

  • Protection Level
  • IP20
  • Humidity
  • Max. 95% relative humidity (Non-condensing)
  • Rated Voltage
  • 24 V DC Volt (V)
  • Efficiency
  • ~0.5 W Typical Power Loss
  • Mounting Type
  • Direct plug-in slot on top of CPU front cover
  • Frequency
  • 50 Hertz (HZ)
  • Input Current
  • Typ. 5 mA from 5V DC backplane bus
  • Operating Temperature
  • -20 C to +60 C Celsius (oC)
  • Usage
  • Industrial Automation
  • Condition
  • New
  • Size
  • 3.8 cm Overall Width
  • Function
  • SB 1231, 1 Analog Input Thermocouple (Isolated sensor channel)
  • Height
  • 6.2 Centimeter (cm)
  • Application
  • Compact S7-1200 CPU expansion for low-footprint temperature monitoring
  • Product Type
  • Thermocouple Analog Input Signal Board (SB 1231 TC)
  • Dimension (L*W*H)
  • 2.1 cm x 3.8 cm x 6.2 cm Centimeter (cm)
  • Weight
  • 0.035 Kilograms (kg)
  • Power Mode
  • Other
  • Color
  • Industrial Gray
  • Length
  • 2.1 Centimeter (cm)
  • Voltage
  • 24 V DC Volt (v)
  • Width
  • 3.8 Centimeter (cm)
  • Power Consumption
  • 0.5 Watt (W)
  • Accessories
  • Included Removable Terminal Block Connector
  • Warranty
  • Standard Siemens Factory Warranty


Siemens, SIMATIC S7-1200, 6ES7231-5QA30-0XB0, 0 DO, 0 DI, 0 AO, 1 AI, Single-phase, 24 V DC. Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Delivery Time
  • 2 Week


About Siemens, SIMATIC S7-1200, 6ES7231-5QA30-0XB0, 0 DO, 0 DI, 0 AO, 1 AI, Single-phase, 24 V DC.

The Siemens SIMATIC S7-1200 SB 1231 TC analog input signal board (model number 6ES7231-5QA30-0XB0) is engineered with 1 analog input (AI) specifically optimized for thermocouple sensor diagnostics, with 0 digital outputs (DO), 0 digital inputs (DI), and 0 analog outputs (AO). Derived from the standard S7-1200 signal board series, it supports Type J or Type K thermocouples with an integrating measurement principle and a precise 15-bit plus sign resolution. Operating on a single-phase central architecture drawing power through the backplane bus using a standard 24 V DC voltage supply, this compact extension card plugs straight into the front faceplate slot of the host CPU. It enables reliable, localized high-accuracy thermal instrumentation monitoring without altering the external physical footprint of your automated PLC panel assembly.
