Siemens, SIMATIC S7-1500, 6ES7522-5EH00-0AB0, N/A (Digital Output Module), 1-Phase (via 24V DC Relay Coil/Internal Supply Layout), 24...48 V UC / 125 V DC.

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens, SIMATIC S7-1500, 6ES7522-5EH00-0AB0, N/A (Digital Output Module), 1-Phase (via 24V DC Relay Coil/Internal Supply Layout), 24...48 V UC / 125 V DC. Specification

Mounting Type
SIMATIC S7-1500 Mounting Rail installation

Output Voltage
120 / 230 V AC (Permitted range: 0 to 264 V AC) Volt (V)

Protection Level
IP20 Protection Rating

Phase
Radio interference suppression Class B equivalent

Input Current
Supply voltage requirement: 24 V DC internal

Efficiency
High switching frequency via solid-state outputs

Rated Voltage
230 V AC Volt (V)

Frequency
47 Hz to 63 Hz line frequency Hertz (HZ)

Humidity
Standard non-condensing industrial operation limits

Operating Temperature
0 C to +60 C (Horizontal deployment standard) Celsius (oC)

Main Material

Usage
Actuator switching, automated industrial AC load control

Processing Type
Standard

Condition
New

Size
35 mm slim high-density output profile

Function
16 Channels in groups of 2 (1 A per channel)

Height
14.7 Centimeter (cm)

Application
Contactors, solenoid valves, small AC motor starters

Product Type
SIMATIC S7-1500 Digital Output Module

Dimension (L*W*H)
12.9 x 3.5 x 14.7 cm Centimeter (cm)

Weight
310 Grams (g)

Power Mode
Other

Color
Industrial Gray / Dark Anthracite

Length
12.9 Centimeter (cm)

Voltage
120 V / 230 V AC Volt (v)

Width
3.5 Centimeter (cm)

Power Consumption
Power loss typ. 10.4 W / Max configuration Watt (W)

Accessories
40-pin Front Connector (Screw/Push-in)

Warranty
Standard manufacturer/distributor warranty

Siemens, SIMATIC S7-1500, 6ES7522-5EH00-0AB0, N/A (Digital Output Module), 1-Phase (via 24V DC Relay Coil/Internal Supply Layout), 24...48 V UC / 125 V DC. Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About Siemens, SIMATIC S7-1500, 6ES7522-5EH00-0AB0, N/A (Digital Output Module), 1-Phase (via 24V DC Relay Coil/Internal Supply Layout), 24...48 V UC / 125 V DC.

The Siemens SIMATIC S7-1500 series digital output module, model number 6ES7522-5EH00-0AB0, acts as a high-density control interface for automation systems. Functioning purely as an expansion hardware component, it does not carry an applicable kw/hp rating and relies on an internal system logic connection. Operating over an independent single-phase channel layout, it features 16 isolated outputs designed to handle flexible switching loads across variable 24...48 V UC and 125 V DC lines.
