PanelView Plus 7 Standard 1000 | 10.4" Touch Terminal, Brandless Front, 24V DC Power

The Allen-Bradley 2711P-T10C22D8S-B is a high-performance 10.4-inch industrial HMI terminal precision-engineered for reliable machine-level control and simplified system diagnostics across factory floors. Belonging to the efficiency-focused PanelView Plus 7 Standard family, the "-B" suffix denotes its unique brandless front panel design. This configuration completely eliminates the standard corporate logo to accommodate customized OEM equipment and clean-room machinery aesthetics. The premium TFT color display features a traditional standard aspect ratio outputting a clear 800 x 600 SVGA resolution with 18-bit color graphics, backed by a solid-state white LED backlight providing long-lasting operational brightness. Operators interact fluently with active automation zones via a highly responsive, analog-resistive touchscreen interface built to endure repetitive industrial plant-floor interactions. [1, 2, 3, 4, 5]

For seamless network integration, the device hosts dual 10/100 Mbps Ethernet ports with an embedded network switch to natively support linear, star, and fault-tolerant Device-Level Ring (DLR) topologies without requiring external networking modules. Operating on a standard, non-isolated 24V DC input power supply (tolerating 18 to 30V DC), it runs efficiently with a maximum power consumption of 35W. Under the hood, it features a stable Windows CE 6.0 operating system license driven by 512 MB of RAM and 512 MB of onboard nonvolatile flash storage (providing roughly 80 MB of free user memory).
