PanelView 5510 | 12" Wide Touchscreen HMI, 24 V DC, Dual Ethernet/DLR

PanelView 5510 | 12" Wide Touchscreen HMI, 24 V DC, Dual Ethernet/DLR About

The Allen-Bradley 2715P-T12WD is a PanelView 5510 Graphic Terminal designed for industrial machine operation, monitoring, and visualization applications. It features a 12.1-inch widescreen color TFT display with 1200 800 WXGA resolution, 16:10 aspect ratio, 24-bit color graphics, and approximately 300 nits brightness. The terminal uses an analog resistive touchscreen with a dedicated menu-navigation button, providing reliable operator interaction in industrial environments. It operates from a 24 V DC supply (1830 V DC) with typical power consumption of approximately 16 W and maximum consumption of 26 W. The unit provides two 10/100Base-T Ethernet ports supporting EtherNet/IP, Device Level Ring (DLR), linear, and star network topologies. It includes 1 GB RAM, 1 GB nonvolatile storage, one SD card slot, and USB connectivity with two USB 2.0 host ports and one USB 2.0 device port. The rugged front provides IP66 and NEMA 4X protection, while the operating temperature range is 0 to +55 C. With approximate front dimensions of 340 246 mm, mounting depth of 64 mm, and weight of approximately 3.61 kg, the 2715P-T12WD is suitable for production machinery, packaging systems, process automation, and industrial control applications. It is programmed through the Studio 5000 environment using View Designer.
