SIMATIC IFP1900 Extended | 19" Industrial Monitor, Display Only, Extended Connection Up to 30m

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIMATIC IFP1900 Extended | 19" Industrial Monitor, Display Only, Extended Connection Up to 30m Specification

Efficiency
High Efficiency

Protection Level
IP65 Front / IP20 Rear

Frequency
50/60 Hertz (HZ)

Humidity
85% Relative Humidity

Mounting Type
Built-in / Panel Mount / Extended transceiver up to 30 meters

Phase
AC Single-phase / DC compatible supply line

Operating Temperature
0 to +45 C Celsius (oC)

Rated Voltage
24 Volt (V)

Main Material

Usage
Industrial Computing / Control & Monitoring

Condition
New

Size
18.5 inch screen diagonal

Function
Extended Visual Display Unit Only (No Touch/Key Inputs)

Height
6.25 Centimeter (cm)

Product Type
SIMATIC IFP1900 Flat Panel Extended Display (No Touch)

Application
Industrial Automation / Flat Panel Monitor System

Weight
5.5 Kilograms (kg)

Dimension (L*W*H)
33.7 48.3 6.25 Centimeter (cm)

Color
Widescreen TFT Display (16.7M colors, 24-bit)

Voltage
24 Volt (v)

Width
48.3 Centimeter (cm)

Length
33.7 Centimeter (cm)

Power Consumption
40 Watt (W)

Accessories
Includes 1.8 m DVI/USB standard connection cable

Warranty
Manufacturer dependent

SIMATIC IFP1900 Extended | 19" Industrial Monitor, Display Only, Extended Connection Up to 30m Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

SIMATIC IFP1900 Extended | 19" Industrial Monitor, Display Only, Extended Connection Up to 30m About

The Siemens 6AV7863-3AB10-0AA0 is a professional-grade 18.5-inch widescreen industrial flat panel monitor precision-engineered for plant control rooms and large-scale machine visualization setups. Part of the prominent SIMATIC Industrial Flat Panel (IFP) portfolio, this specific model is a display-only version configured without any touchscreen functionality, serving strictly as a durable video receiver terminal with zero integrated mechanical control elements. It features a premium TFT widescreen layout with a 16:9 aspect ratio, outputting a crisp 1366 x 768 pixel resolution and over 16 million colors backed by an energy-efficient, long-lasting LED backlight. As an Extended version, it incorporates specialized signal transceivers that allow it to be installed at a long transmission distance of up to 30 metres away from the central industrial computing host. [1, 2, 3]

Built to survive aggressive factory floor variables, the unit is constructed with a rugged aluminum front housing and a non-reflective, tempered mineral glass screen that provides premium mechanical protection against high pressure and abrasive scratching. The front face carries a protective IP65/NEMA 4x environmental rating to completely block out fine industrial dust, grease, and liquid splashes
