SIPLUS HMI KTP700 Basic | 7-inch widescreen TFT key/touchscreen, PROFINET interface, USB host, 65,536 colors, Front IP65, medial conformal coating for standard extreme environments

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIPLUS HMI KTP700 Basic | 7-inch widescreen TFT key/touchscreen, PROFINET interface, USB host, 65,536 colors, Front IP65, medial conformal coating for standard extreme environments Specification

Humidity
100% Relative Humidity with condensation/frost permissible

Rated Voltage
24 V DC Volt (V)

Operating Temperature
-20 C to +60 C Celsius (oC)

Phase
N/A (Direct Current infrastructure alignment)

Mounting Type
Control Panel Cutout via Integrated Tightening Clamps

Input Current
Typ. 230 mA / Max. 440 mA from 24V DC terminal

Efficiency
Dimmable Backlight (0 to 100%) optimizing power consumption

Protection Level
IP65 Front / IP20 Back Enclosure

Main Material

Usage
Industrial Machine Interface & Control

Condition
New

Size
7.0" Diagonal Display Profile Space Footprint

Function
100% Relative Humidity with condensation/frost permissible

Height
15.4 Centimeter (cm)

Application
Operator interface control in aggressive atmospheres or outdoor cabinets

Product Type
SIPLUS HMI Basic Panel (2nd Generation)

Weight
0.78 Kilograms (kg)

Dimension (L*W*H)
3.9 cm x 21.4 cm x 15.4 cm Centimeter (cm)

Power Mode
Other

Color
Industrial Gray Front / Black Border Trim

Width
21.4 Centimeter (cm)

Length
3.9 Centimeter (cm)

Voltage
24 V DC Volt (v)

Power Consumption
5.5 Watt (W)

Accessories
Required Terminal Strip Connectors & Cutout Gaskets

Warranty
Standard Siemens Factory Warranty

SIPLUS HMI KTP700 Basic | 7-inch widescreen TFT key/touchscreen, PROFINET interface, USB host, 65,536 colors, Front IP65, medial conformal coating for standard extreme environments Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About SIPLUS HMI KTP700 Basic | 7-inch widescreen TFT key/touchscreen, PROFINET interface, USB host, 65,536 colors, Front IP65, medial conformal coating for standard extreme environments

Empower your mid-range industrial automation in harsh conditions with the ruggedized Siemens SIPLUS HMI KTP700 Basic Panel. Specially built on the hardware architecture of the standard 7-inch model (6AV2123-2GB03-0AX0), this hardened 2nd-generation console features an advanced polymeric conformal coating to defend internal circuitry from moisture, condensation, and corrosive gases. It operates reliably across an expanded thermal window from -20 C up to +50 C, ensuring stable performance through intense environmental swings. The interface pairs an expansive 7-inch widescreen TFT touch display with 8 programmable tactile function keys to provide versatile, hybrid operator control for complex machine layouts. A single integrated PROFINET interface facilitates fast, high-speed Ethernet connection to modern PLCs, while a built-in USB host port accelerates peripheral integration and secure operational data archiving. Complete with a dust-tight, water-resistant IP65-rated front faceplate, it delivers ultimate, protected visualization directly on high-stress factory floors.
