SIMATIC IFP1500 Extended | 15" Industrial Multi-Touch Monitor, Marine Approved, Extended Connection

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIMATIC IFP1500 Extended | 15" Industrial Multi-Touch Monitor, Marine Approved, Extended Connection Specification

Efficiency
High Efficiency

Operating Temperature
0 to +50 C Celsius (oC)

Protection Level
IP65 Front / IP20 Rear

Humidity
95% Relative Humidity (Non-condensing)

Frequency
50/60 Hertz (HZ)

Mounting Type
Built-in / Panel Mount / Extended transceiver up to 30 meters

Phase
AC Single-phase / DC compatible supply line

Rated Voltage
24 Volt (V)

Input Current
1.9 A (at 24V DC) / 0.85 A (at 120V AC)

Usage
Industrial Computing / Control & Monitoring (Marine Environment)

Main Material

Size
15.6 inch screen diagonal

Condition
New

Height
6.25 Centimeter (cm)

Function
Operator Control, Widescreen Multitouch Panel

Application
Maritime Automation / Shipboard Extended Remote Station Control

Product Type
SIMATIC IFP1500 Flat Panel Marine (Multitouch - Extended)

Dimension (L*W*H)
29.8 41.65 6.25 Centimeter (cm)

Weight
4.2 Kilograms (kg)

Power Mode
Other

Color
Widescreen TFT Display (16.7M colors)

Length
29.8 Centimeter (cm)

Width
41.65 Centimeter (cm)

Voltage
24 Volt (v)

Power Consumption
40 Watt (W)

Accessories
Includes 1.8 m DVI/USB connection cable

Warranty
Manufacturer dependent

SIMATIC IFP1500 Extended | 15" Industrial Multi-Touch Monitor, Marine Approved, Extended Connection Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About SIMATIC IFP1500 Extended | 15" Industrial Multi-Touch Monitor, Marine Approved, Extended Connection

The Siemens 6AV7863-2MB10-0SA0 is a professional-grade 15.6-inch widescreen industrial flat panel monitor precision-engineered for maritime operations and harsh offshore machine-level visualization. Based on the robust SIMATIC Industrial Flat Panel (IFP) framework, this specialized variant is reinforced with formal shipbuilding and marine approvals to meet stringent safety, vibration, and environmental standards required on ships and open-sea platforms. It features a premium TFT widescreen layout with a 16:9 aspect ratio, outputting a crisp 1366 x 768 pixel resolution and over 16 million colors backed by an energy-efficient, dimmable LED backlight. It incorporates highly responsive, protective projected capacitive multi-touch technology that enables fluent, intuitive gesture interactions under demanding marine and factory-floor operating conditions.

As an Extended version, it incorporates specialized signal transceivers that allow it to be installed at a long transmission distance of up to 30 metres away from the central industrial computing host. Built to survive aggressive variables, the unit is constructed with a rugged build that provides a protective IP65 environmental rating at the front to block out fine dust, salt mist, and liquid splashes.
