SIMATIC HMI MTP700 Unified Comfort Panel Hygienic | 7-inch widescreen TFT touchscreen, stainless steel hygienic design, PROFINET/Ethernet, 16 million colors, Front IP69, food & beverage and pharmaceutical machine visualization

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIMATIC HMI MTP700 Unified Comfort Panel Hygienic | 7-inch widescreen TFT touchscreen, stainless steel hygienic design, PROFINET/Ethernet, 16 million colors, Front IP69, food & beverage and pharmaceutical machine visualization Specification

Humidity
Max. 90% relative humidity (Non-condensing structural system bounds)

Phase
N/A (Direct Current infrastructure alignment)

Input Current
Typ. 0.4 A (400 mA current draw) / Max. 0.9 A at 24V line interface

Efficiency
Dynamic Backlight Dimming (0 to 100%) optimizing cleanroom operation

Rated Voltage
24 V DC Volt (V)

Protection Level
IP69 Front

Mounting Type
Panel Cutout Installation with FDA-Compliant Rear Gasket Strip

Operating Temperature
0 C to +50 C Celsius (oC)

Main Material

Usage
Food & Beverage / Pharmaceutical Automation

Condition
New

Size
7.0" Diagonal Widescreen Display Space Footprint

Height
17.2 Centimeter (cm)

Function
MTP700 Unified Multi-Touch Hygienic panel with 16 million colors

Product Type
SIMATIC HMI Unified Comfort Hygienic Series

Application
Splash-zone monitoring, splash/cleanroom data collection, and edge apps

Weight
1.70 Kilograms (kg)

Dimension (L*W*H)
6.7 cm x 23.4 cm x 17.2 cm Centimeter (cm)

Color
Silver (Stainless Steel Front Faceplate)

Power Mode
Other

Length
6.7 Centimeter (cm)

Voltage
24 V DC Volt (v)

Width
23.4 Centimeter (cm)

Power Consumption
11 Watt (W)

Accessories
Blue FDA-Compliant Gasket Strip & Splash Protection Clamps

Warranty
Standard Siemens Factory Warranty

SIMATIC HMI MTP700 Unified Comfort Panel Hygienic | 7-inch widescreen TFT touchscreen, stainless steel hygienic design, PROFINET/Ethernet, 16 million colors, Front IP69, food & beverage and pharmaceutical machine visualization Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About SIMATIC HMI MTP700 Unified Comfort Panel Hygienic | 7-inch widescreen TFT touchscreen, stainless steel hygienic design, PROFINET/Ethernet, 16 million colors, Front IP69, food & beverage and pharmaceutical machine visualization

Unlock next-generation industrial automation in sanitary production zones with the Siemens SIMATIC HMI MTP700 Unified Comfort Panel Hygienic. This premium 7-inch widescreen TFT touchscreen delivers stunning machine visualization through 16 million brilliant colors and a crisp 800 x 480 pixel resolution. Engineered explicitly for strict sanitary environments, its rugged stainless steel bezel features a blue FDA-compliant gasket and a splinter-protected display front compliant with DIN EN 1672-2 and FDA 21 CFR 177.2006 directives. The capacitive multi-touch interface allows seamless gesture-based control, while an extreme IP69 protection rating allows for high-pressure, hot-water washdowns. Driven by HTML5 web technologies and Siemens Industrial Edge capability, this panel transforms raw operational data into actionable, real-time insights. Elevate your plant control architecture, enforce strict hygiene compliance, and future-proof your smart factory operations with this sleek, washdown-ready visualization masterpiece.
