SIMATIC HMI MTP1900 Unified Comfort PRO | 18.5-inch widescreen TFT touchscreen, support arm mounting (top flange, non-expandable), PROFINET/Ethernet, 16 million colors, IP65 all-round protection, machine-level visualization

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SIMATIC HMI MTP1900 Unified Comfort PRO | 18.5-inch widescreen TFT touchscreen, support arm mounting (top flange, non-expandable), PROFINET/Ethernet, 16 million colors, IP65 all-round protection, machine-level visualization Specification

Mounting Type
Direct support arm system installation (Suitable for top or bottom pipe mechanisms)

Phase
N/A (Direct Current infrastructure alignment)

Protection Level
IP65

Input Current
Typ. 1.2 A (1200 mA current draw) / Max. 1.7 A at 24V line interface

Operating Temperature
0 C to +40 C Celsius (oC)

Efficiency
Dynamic Backlight Dimming (10 to 100%) optimizing power consumption

Humidity
Max. 90% relative humidity (Non-condensing structural system bounds)

Rated Voltage
24 V DC Volt (V)

Usage
High-Performance Industrial Automation

Main Material

Size
18.5" Diagonal Widescreen Display Space Footprint

Condition
New

Function
MTP1900 Unified Multi-Touch rugged operation panel with 16 million colors

Height
35.5 Centimeter (cm)

Product Type
SIMATIC HMI Unified Comfort PRO System

Application
Premium machine-level process monitoring, graphics tracking, and Edge app installations

Dimension (L*W*H)
11.2 cm x 46.2 cm x 35.5 cm Centimeter (cm)

Weight
7.20 Kilograms (kg)

Color
Industrial Gray Front / Black Border Trim

Power Mode
Other

Width
46.2 Centimeter (cm)

Length
11.2 Centimeter (cm)

Voltage
24 V DC Volt (v)

Power Consumption
28.8 Watt (W)

Accessories
Requires support arm adapter installation kits (Ordered Separately)

Warranty
Standard Siemens Factory Warranty

SIMATIC HMI MTP1900 Unified Comfort PRO | 18.5-inch widescreen TFT touchscreen, support arm mounting (top flange, non-expandable), PROFINET/Ethernet, 16 million colors, IP65 all-round protection, machine-level visualization Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About SIMATIC HMI MTP1900 Unified Comfort PRO | 18.5-inch widescreen TFT touchscreen, support arm mounting (top flange, non-expandable), PROFINET/Ethernet, 16 million colors, IP65 all-round protection, machine-level visualization

Unlock next-generation industrial automation directly at the machine with the Siemens SIMATIC HMI MTP1900 Unified Comfort PRO Panel. This premium 18.5-inch widescreen TFT touchscreen delivers breathtaking visualization through 16 million brilliant colors and crisp 1920 x 1080 Full HD resolution. Specially engineered for cabinet-free installation, its rugged, fully enclosed housing features a top flange connection designed for direct support arm mounting without extension components. The high-performance capacitive multi-touch glass front allows seamless, gesture-based controleven while wearing industrial work gloves. Packed with high-speed PROFINET/Ethernet interfaces, it ensures lightning-fast data exchange and effortless integration across your plant floor. Boasting complete IP65 all-round protection, this powerhouse withstands extreme vibration, dust, and liquid splashes in heavy-duty manufacturing environments. Driven by HTML5 web technologies and Siemens Industrial Edge capability, this panel transforms raw operational data into actionable, real-time insights. Elevate your control architecture, minimize costly downtime, and future-proof your smart factory operations with this sleek, ultra-reliable visualization masterpiece.
