Siemens SIMATIC S7-200 SMART Analog Output Module

Siemens SIMATIC S7-200 SMART Analog Output Module About

The Siemens 6ES7288-3AQ02-0AA0 is an active, compact SIMATIC S7-200 SMART analog output expansion module (EM AQ02) designed to modulate precise actuator commands in small-to-medium process control systems. This 45mm-wide module expands your PLC configuration by adding two analog outputs.Engineered for highly versatile field control, each channel can be custom-programmed to output standard industrial control vectors, including voltage (10V) or current (020 mA, 420 mA). It operates at an 11-bit plus sign resolution for voltage signals and an 11-bit resolution for current loops. Housed in a dense, IP20-protected enclosure meant for standard DIN rail layouts, the module features low thermal impact with a typical power loss of 1.5W. Front-facing LEDs provide rapid diagnosis of power supply health and signal state errors.
