Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

Send Inquiry

Request To Call Back

Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC. Specification

Operating Temperature
-20 C to +60 C Celsius (oC)

Output Voltage
24 V DC Volt (V)

Humidity
Max. 95% relative humidity (Non-condensing)

Rated Voltage
24 V DC Volt (V)

Protection Level
IP20

Efficiency
~1.5 W Typical Power Loss

Mounting Type
Direct plug-in slot on top of CPU front cover

Frequency
200 Kilohertz ( KHZ )

Input Current
Typ. 50 mA from 5V DC Backplane bus

Main Material

Usage
Industrial Automation

Size
3.8 cm Overall Width

Condition
New

Height
6.2 Centimeter (cm)

Function
SB 1222, 4 Digital Outputs (24V DC / 0.1A sourcing transistor)

Application
S7-1200 CPU expansion for fast pulse-train switching output loops

Product Type
Digital Output Signal Board (SB 1222)

Dimension (L*W*H)
2.1 cm x 3.8 cm x 6.2 cm Centimeter (cm)

Weight
0.04 Kilograms (kg)

Color
Industrial Gray

Width
3.8 Centimeter (cm)

Voltage
24 V DC Volt (v)

Length
2.1 Centimeter (cm)

Power Consumption
1.5 Watt (W)

Accessories
Required Removable Terminal Connector Block

Warranty
Standard Siemens Factory Warranty

Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC. Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About Siemens, SIMATIC S7-1200, 6ES7222-1BD30-0XB0, 4 DO, 0 DI, 0 AO, 0 AI, Single-phase, 24 V DC.

The Siemens SIMATIC S7-1200 SB 1222 digital output signal board (model number 6ES7222-1BD30-0XB0) features 4 digital outputs (DO) driven by high-speed MOSFET transistors, alongside 0 digital inputs (DI), 0 analog outputs (AO), and 0 analog inputs (AI). It interfaces seamlessly inside a single-phase controller architecture utilizing a standard 24 V DC switching voltage. This compact extension board mounts directly into the front signal board slot of the host CPU to provide localized, high-speed switching capabilities up to 200 kHz without altering the physical footprint of the PLC configuration.
