PanelView Plus 7 Standard | 15" Touchscreen HMI, XGA, Single Ethernet, 24 V DC

PanelView Plus 7 Standard | 15" Touchscreen HMI, XGA, Single Ethernet, 24 V DC About

The Allen-Bradley 2711P-T15C21D8S-B is a PanelView Plus 7 Standard industrial operator terminal designed for machine operation, process monitoring, and visualization applications. It features a 15-inch color TFT touchscreen display with 1024 768 XGA resolution, 18-bit color graphics, and approximately 300 nits brightness. The analog-resistive touchscreen provides reliable direct operator interaction and is rated for approximately 1 million actuations. The terminal provides single 10/100Base-T Ethernet communication for EtherNet/IP-based industrial networks and operates from a 24 V DC supply.

The unit uses Windows CE 6 and supports FactoryTalk View Machine Edition applications. It includes USB connectivity and removable SD-card storage for application transfer and maintenance. The front is designed for harsh industrial environments with NEMA/UL Type 12, 13 and 4X indoor-use protection, and is classified for IP54/IP66 protection. The operating temperature range is 0 to +55 C, with approximately 30 W heat dissipation for the 15-inch model.
