Mitsubishi QJ72LP25G

Get a Price/Quote

Mitsubishi QJ72LP25G Specification

Phase
Single phase

Frequency
50/60 Hz

Protection Level
IP20

Mounting Type
DIN rail

Efficiency
High efficiency digital module

Humidity
5 to 95% RH (non-condensing)

Operating Temperature
0 to 55C

Input Current
0.15 A

Rated Voltage
24V DC

Main Material
Plastic, PCB

Processing Type
Electronic Module

Condition
New

Function
Master/local station module for CC-Link network communication

Application
MELSEC Q series PLC systems, Communication module for CC-Link

Dimension (L*W*H)
98 x 27.4 x 90 mm

Power Mode
External power supply

Voltage
24V DC

Power Consumption
3.5 W

Storage Temperature
-25 to 75°C

Number of CC-Link Stations
Up to 64

Compliance
CE, UL, cUL

Max Communication Distance
Up to 1200 m (depends on speed)

Transmission Speed
156 kbps to 10 Mbps

Model
QJ72LP25G

Release Year
2022

Communication Ports
1 port (CC-Link)

Compatible PLC Series
MELSEC Q Series

Product Type
CC-Link Communication Module

Weight
0.19 kg

Status LED Indicators
Yes

About Mitsubishi QJ72LP25G

Shop Now for the acclaimed Mitsubishi QJ72LP25G CC-Link Communication Module, a venerable ace for advanced industrial automation. This unassailable module supports up to 64 CC-Link stations and boasts transmission speeds ranging from 156 kbps to a swift 10 Mbps. Designed for MELSEC Q Series PLCs, its 1 communication port offers seamless integration with master or local station roles. At 0.19kg, its compact build comes CE, UL, and cUL certified, ensuring reliability. Experience high efficiency and secure, IP20-level protection. Special Rate available-order direct from a trusted Indian exporter, manufacturer, supplier, or trader today!

Versatile Application and Usage of the Mitsubishi QJ72LP25G

The Mitsubishi QJ72LP25G CC-Link Communication Module excels in MELSEC Q Series PLC systems, serving as either a master or local station module for robust network communication. It is ideal for industrial environments requiring precise and high-speed data exchange across up to 64 CC-Link stations. This module is best suited for DIN rail mounting within control cabinets, ensuring efficient connectivity. Designers, engineers, and integrators favor this module for its reliable performance and straightforward configuration within automation networks.

Certifications, Shipping, and Payment Facilities for the QJ72LP25G

The Mitsubishi QJ72LP25G upholds several unassailable certifications, including CE, UL, and cUL, underscoring its ace status in compliance and safety standards. FOB port options are available for global shipment, making order completion and outlay calculation efficient for buyers. Customers benefit from flexible payment terms, ensuring a seamless purchasing process. Each order is handled with care by our experienced export and supply chain teams, ensuring prompt, accurate, and protected delivery of your modules every time.

FAQ's of Mitsubishi QJ72LP25G:

Q: How is the Mitsubishi QJ72LP25G installed in automation systems?

A: The QJ72LP25G is mounted on a DIN rail within control panels and connected to MELSEC Q Series PLCs using its dedicated CC-Link port for seamless network communication.

Q: What certifications does the QJ72LP25G have?

A: This module holds CE, UL, and cUL certifications, ensuring compliance with key international safety and quality standards.

Q: Where can I use the QJ72LP25G module?

A: It is intended for integration into industrial automation environments that require secure, high-speed communication among up to 64 devices on a CC-Link network.

Q: What benefits does the QJ72LP25G offer to automation engineers?

A: Engineers benefit from its high efficiency, versatile communication roles, status LED indicators, and robust compliance, enabling reliable operations and simplified troubleshooting.

Q: What is the process for ordering and receiving the QJ72LP25G?

A: Customers can place orders through authorized exporters, manufacturers, suppliers, or traders in India, with shipment arranged via FOB port and flexible payment terms for swift order completion.
