Mitsubishi QJ72LP25-25

Get a Price/Quote

Mitsubishi QJ72LP25-25 Specification

Rated Voltage
24 V DC

Humidity
5% to 95% RH (non-condensing)

Efficiency
High

Phase
Single Phase

Output Voltage
24 VDC

Frequency
50/60 Hz

Operating Temperature
0C to +55C

Mounting Type
DIN Rail Mounting

Protection Level
IP20

Input Current
0.13 A (at 24VDC)

Main Material
Plastic, Metal

Processing Type
Electronic

Condition
New

Function
PLC Link Module for CC-Link

Application
Programmable Controller Networking

Dimension (L*W*H)
98 x 27.4 x 90 mm

Power Mode
DC Powered

Voltage
24 V DC

Power Consumption
2.5 W

Accessories
User Manual, Mounting Screws

Ambient Storage Temperature
-25C to +75C

Module Type
CC-Link Master/Local Module

Number of Channels
2

Product Code
QJ72LP25-25

Dielectric Strength
560 VAC, 1 minute

Network Type
CC-Link

Weight
0.17 kg

Insulation Resistance
500 M minimum (500 VDC megger)

Maximum Stations
64 Stations per Network

Color
Grey

Applicable PLC Series
Mitsubishi MELSEC-Q Series

Communication Speed
156 kbps to 10 Mbps

About Mitsubishi QJ72LP25-25

Experience unassailable performance and unparalleled reliability with the Mitsubishi QJ72LP25-25 CC-Link Master/Local Module. Engineered to be top-ranking among programmable controller networking modules, it supports high-speed communication from 156 kbps to 10 Mbps and operates seamlessly with up to 64 network stations. Its lightweight form factor (0.17 kg), robust insulation resistance, and IP20 protection level ensure resilience in demanding industrial environments. Add to Cart now to explore efficient automation with Mitsubishi MELSEC-Q Series compatibility. Try Now and unlock advanced connectivity for your PLC network systems.

Exceptional Features and Easy Integration

The Mitsubishi QJ72LP25-25 excels with a dual-channel design, wide communication speeds, and simple DIN rail mounting for intuitive installation. Users are advised to follow the user manual for quick setup and efficient integration. Its primary advantages include high efficiency, excellent insulation, and unmatched network expansion. The superior build quality with plastic and metal materials ensures consistent function, making it the preferred choice in industrial automation.

Reliable Supply and Smooth Dispatch Solutions

For domestic markets or bulk requirements in India, our stock is ready for immediate dispatching. The Mitsubishi QJ72LP25-25 is packed securely with a user manual and mounting screws to guarantee product safety. We accommodate flexible payment terms and maintain strong supply ability to meet urgent and ongoing needs. Trust our expertise for seamless order processing and swift nationwide delivery, providing reliability for manufacturers, exporters, and suppliers alike.

FAQ's of Mitsubishi QJ72LP25-25:

Q: How do I install the Mitsubishi QJ72LP25-25 module in my PLC system?

A: Installation is straightforward: mount the module on a DIN rail, connect the relevant cables as detailed in the user manual included, and ensure power is supplied at 24V DC for optimal operation.

Q: What are the main benefits of using the QJ72LP25-25 in industrial automation?

A: The module offers high-speed communication, robust reliability, and expandable networking-with support for up to 64 stations-ensuring improved system efficiency and easy integration into MELSEC-Q Series environments.

Q: Where can the Mitsubishi QJ72LP25-25 be effectively utilized?

A: Its primary application is in programmable controller networking within industrial automation setups, especially where scalable CC-Link networks are crucial.
