Mitsubishi Q64ADH

Get a Price/Quote

Mitsubishi Q64ADH Specification

Input Current
020mA, 420mA

Frequency
50/60 Hz

Efficiency
High efficiency, industrial use

Phase
Single phase

Rated Voltage
24V DC

Mounting Type
DIN Rail

Humidity
5% to 95% RH (non-condensing)

Operating Temperature
0 to 55C

Protection Level
IP20

Main Material
Plastic/Metal

Processing Type
Analog/Digital Conversion

Condition
New

Function
4-Channel Analog Input Module

Application
PLC analog input module for automation systems

Dimension (L*W*H)
98mm 27.4mm 90mm

Power Mode
External power supply

Voltage
24 V DC

Power Consumption
Max. 7.5W

Accessories
User Manual

Input Range
-10 to +10V, 020mA, 420mA

Response Speed
High speed response

Storage Temperature
-25C to +75C

Isolation
Input channels and system separated by photocoupler

Compatible Series
MELSEC Q Series PLC

Input Type
Voltage/Current

Weight
0.16 kg

Signal Type
Analog Input

Conversion Speed
600 s/ch

Resolution
16-bit

Standards/Certification
CE, UL, cUL

Input Channels
4 channels, differential

Model Number
Q64ADH

About Mitsubishi Q64ADH

Experience reduced operational concerns and top industrial performance with the Mitsubishi Q64ADH. This opulent 4-channel analog input module delivers eminent accuracy through its radiant 16-bit resolution and rapid 600 s/ch conversion speed. Its versatile input handling accommodates -10 to +10V and both 0-20mA and 4-20mA signals. Featuring robust photocoupler isolation and certified to CE, UL, and cUL standards, the Q64ADH stands as the pinnacle of reliability. Offered at a reduced price, it integrates seamlessly with MELSEC Q Series PLC systems for advanced automation applications.

Extensive Application Surface & Use Type

The Mitsubishi Q64ADH radiates versatility across high-tech automation environments. Designed for use in industrial automation, this module excels in process control and monitoring applications. Its DIN Rail mounting and IP20 protection make it ideal for various PLC installations, empowering users with reliable analog/digital conversion. Whether for manufacturer, exporter, or supplier purposes, the Q64ADH offers robust solutions for both new setups and system expansions, ensuring high efficiency and precision in every use case.

Valuation, Dispatch & Certifications

Enjoy premium valuation with the Mitsubishi Q64ADH, backed by CE, UL, and cUL certifications ensuring compliance and trust. Sample modules may be dispatched upon request for evaluation purposes, supporting informed purchasing decisions. Payment terms are flexible, tailored to meet business requirements for exporters and domestic traders alike. Whether for large-scale procurement or single module needs, buyers are guaranteed a superior product that embodies efficacy and top-tier safety standards.

FAQ's of Mitsubishi Q64ADH:

Q: How does the Mitsubishi Q64ADH analog input module benefit industrial automation systems?

A: The Q64ADH offers high-speed, accurate analog signal conversion, robust isolation, and exceptional reliability, enhancing overall system efficiency and data integrity in demanding automation environments.

Q: What input types and ranges does the Q64ADH support?

A: This module supports both voltage (-10 to +10V) and current (0-20mA, 4-20mA) analog signals over four differential channels, ensuring flexibility across diverse process requirements.

Q: When can a sample of Mitsubishi Q64ADH be dispatched?

A: Samples can typically be dispatched promptly upon request and confirmation, assisting with product evaluation and integration planning.

Q: Where is the Mitsubishi Q64ADH best utilized?

A: It is best utilized in industrial PLC automation systems requiring reliable analog input, such as manufacturing plants, process control, and high-efficiency monitoring applications.
