Mitsubishi Q64AD

Get a Price/Quote

Mitsubishi Q64AD Specification

Humidity
5% to 95% RH (non-condensing)

Protection Level
IP20

Frequency
50/60 Hz

Mounting Type
DIN rail

Efficiency
High precision analog conversion

Phase
Single

Rated Voltage
24 VDC

Operating Temperature
0C to +55C

Input Current
0-20 mA (per channel)

Main Material
Plastic, electronic components

Processing Type
Analog signal acquisition

Condition
New

Function
4-channel analog input module

Application
Analog input module for Mitsubishi MELSEC Q Series PLC

Dimension (L*W*H)
98 x 27.4 x 90 mm

Power Mode
DC

Voltage
24 VDC (internal power supply)

Power Consumption
4.5 W

Accessories
Manual

Response Time
Less than 10 ms

Input Range
0-10V, 1-5V, ±10V, 0-20mA, 4-20mA

Weight
0.16 kg

Series
MELSEC Q Series

Isolation
Channel-to-PLC isolated

Analog Inputs
4 channels

Model Number
Q64AD

Resolution
16 bits

About Mitsubishi Q64AD

The Mitsubishi Q64AD analog input module is an in demand and top-drawer solution engineered for the MELSEC Q Series PLC. This opulent device is designed with four high-precision channels supporting voltage and current ranges of 0-10V, 1-5V, 10V, 0-20mA, and 4-20mA. Its world-class 16-bit resolution ensures accurate analog signal acquisition, ideal for applications requiring rapid response times under 10 ms. Currently scarce due to high demand, grab yours in this exclusive clearance as a reliable, high-performing addition to your automation lineup. Manufactured in India, exporter, supplier, and trader backed.

Ideal Usage and Application Areas

The Mitsubishi Q64AD is widely used by automation engineers, process control professionals, and system integrators. This module is suitable for use in high-precision manufacturing plants, industrial automation, and critical process control environments. Common sites of application include factory floors, research facilities, and complex industrial systems requiring reliable analog data acquisition and monitoring.

Sample Availability & Market Information

Mitsubishi Q64AD samples are available and dispatched promptly to facilitate easy evaluation. We offer the lowest price for bulk orders in various main export markets, including Southeast Asia, the Middle East, and Africa, with fast delivery across India's main domestic markets. Estimate your project timelines confidently, knowing that exceptional clearance deals and customer support are assured with every order.

FAQ's of Mitsubishi Q64AD:

Q: How does the Mitsubishi Q64AD module enhance analog signal processing?

A: The Q64AD offers high-precision 16-bit resolution with rapid response times under 10 ms, delivering reliable and accurate analog signal acquisition critical for process control applications.

Q: What is the input range supported by the Q64AD module?

A: This module supports multiple input ranges including 0-10V, 1-5V, 10V for voltage signals, and 0-20mA, 4-20mA for current signals, providing flexibility to accommodate diverse sensor inputs.

Q: Where is the Mitsubishi Q64AD typically installed?

A: It is typically mounted on a DIN rail within control panels in factories, research labs, or industrial plants as part of the Mitsubishi MELSEC Q Series PLC system for analog data collection.

Q: When should I consider replacing or upgrading to the Q64AD?

A: Consider upgrading to the Q64AD when your PLC system requires faster, more accurate analog input, or when current modules are outdated and lack adequate resolution or isolation.

Q: What is the process for installing the Mitsubishi Q64AD module?

A: Installation involves securing the module to a DIN rail, connecting analog input channels and power supply (24 VDC), then interfacing it with the MELSEC Q Series PLC as per the provided manual.

Q: What benefits does the Q64AD offer for industrial automation?

A: The Q64AD delivers top-drawer performance in high-efficiency analog conversion, robust isolation for signal integrity, and compatibility with a wide range of industrial and manufacturing applications.
