Mitsubishi FX5-485-BD

Get a Price/Quote

Mitsubishi FX5-485-BD Specification

Phase
Single Phase (main unit)

Mounting Type
Direct on PLC Main Unit

Protection Level
IP20

Humidity
5% to 95% RH, Non-condensing

Input Current
Drawn from main unit (minimal)

Efficiency
High (communication expansion)

Operating Temperature
0C to +55C

Rated Voltage
24V DC

Frequency
50/60 Hz (main unit reference)

Main Material
ABS Resin, Electronic Components

Processing Type
Industrial Automation

Condition
New

Function
Expands PLC capabilities with RS-485 serial communication

Application
RS-485 Communication Expansion Board for FX5U/FX5UC PLC

Dimension (L*W*H)
31 x 90 x 86 mm (approx)

Power Mode
Powered via PLC main unit

Voltage
24V DC (from base unit)

Power Consumption
0.6W (typical)

Accessories
User Manual

Connector Type
Screw terminal

Baud Rate
Up to 115.2kbps

Interface Type
RS-485 (2-wire, half-duplex)

Max Communication Distance
Up to 1200 meters

Communication Protocols
MODBUS RTU, Mitsubishi Dedicated Protocol

Isolation
Non-isolated

Weight
Approx. 100g

Number of Communication Ports
1 port (RS-485)

Compatible Mitsubishi Models
FX5U, FX5UC series

Installation Method
Expansion board, direct attach to PLC

About Mitsubishi FX5-485-BD

Discover the Mitsubishi FX5-485-BD, a top-rated RS-485 communication expansion board for FX5U and FX5UC PLC series-now at an unbeatable price with an exclusive price cut. Built with impeccable industrial-grade ABS resin and robust electronic components, this champion accessory ensures seamless MODBUS RTU or Mitsubishi Protocol communication up to 1200 meters at 115.2kbps. Its compact, direct-attach design and non-isolated screw terminal connector make installation effortless, while high efficiency and minimal input current maintain optimal productivity. Supplied brand new, this expansion board is a must-have for automation champions across India.

Versatile Usage and Plant Application

The Mitsubishi FX5-485-BD excels in industrial automation, serving as a reliable RS-485 communication expansion for FX5U/FX5UC PLCs. Ideal for large-scale manufacturing plants, processing facilities, and automated control systems, it extends communication capabilities where robust, multi-point data exchange is vital. Designed for direct attachment to your PLC, it enhances machine connectivity and streamlines plant operations, making it a preferred solution for industrial process automation and plant-wide communications.

Supply Ability, Order Processing, and Packaging

As a premier exporter, manufacturer, supplier, and trader in India, we ensure consistent supply and timely delivery of the Mitsubishi FX5-485-BD. Your orders are processed promptly, with each unit securely packaged to guarantee safe goods transport. Flexible payment terms make procurement easy, meeting various business needs. Rely on our efficient supply chain and comprehensive order processing for hassle-free acquisition of this essential expansion board, providing you with smooth operations and uninterrupted automation support.

FAQ's of Mitsubishi FX5-485-BD:

Q: How does the Mitsubishi FX5-485-BD board enhance PLC communication?

A: The FX5-485-BD expansion board adds RS-485 serial communication capability to FX5U and FX5UC series PLCs, supporting MODBUS RTU and Mitsubishi Dedicated Protocol for seamless multi-device integration.

Q: What are the installation requirements for this RS-485 communication expansion?

A: The board installs directly onto the PLC main unit using an expansion slot. No external power supply is needed, as it draws power and references from the main unit.

Q: When should I choose the FX5-485-BD for my automation setup?

A: Select this board when you need reliable, long-distance RS-485 communications (up to 1200 meters) within industrial or plant automation systems, especially where MODBUS RTU protocol integration is vital.

Q: Where can this product be applied in industrial settings?

A: FX5-485-BD is suitable for deployment in manufacturing plants, processing facilities, and automation centers looking to expand their PLC communication capacities.

Q: What protocols are supported by the FX5-485-BD?

A: This board supports both MODBUS RTU and the Mitsubishi Dedicated Protocol, offering flexibility for a wide range of industrial applications.

Q: How does the non-isolated RS-485 interface affect usage?

A: The non-isolated interface simplifies installation but should be used where electrical isolation between communication devices is not critical for your automation requirements.
