Mitsubishi BL296PB-08F

Get a Price/Quote

Mitsubishi BL296PB-08F Specification

No Of Core
Single

Temperature
-10C to 60C

Cable Length
Depends on installation

Conductor Type
Single core

Connector Type
Screw terminal

Product Type
BL296PB-08F Relay Module

Material
Plastic & Metal

Function
Control and switching applications

Usage
Industrial automation, electrical panels

Voltage Surge
Up to 250V

Frequency (MHz)
50/60 Hz

Rated Voltage
24V DC

Rated Current
8A

Cable Capacity
Suitably sized for rated current

Insulation Material
High-grade plastic

Conductor Material
Copper

Length
Standard module size

Size
Compact module (approx. 87mm x 25mm x 56mm)

Color
Black

Diameter
Module diameter as per specifications

Application
Automation Equipment

Response Time
<20 ms

Weight
Approx. 120 grams

Relay Type
Electromechanical relay

Mounting Type
DIN Rail Mount

Model Number
BL296PB-08F

Contact Configuration
SPDT (Single Pole Double Throw)

Life Expectancy
>100,000 operations

Humidity Tolerance
Max 85% RH (non-condensing)

Dielectric Strength
>1000V AC

Protection Level
IP20

About Mitsubishi BL296PB-08F

Purchase the kingly Mitsubishi BL296PB-08F at an exclusive price cut, delivering phenomenal value for industrial automation needs. This opulent electromechanical relay features DIN rail mount adaptability, SPDT configuration, and robust build with high-grade plastic and metal. With a rapid response time (<20 ms), IP20 protection, and over 100,000 operational cycles, it brings precision and longevity to control and switching applications. Rated at 24V DC, 8A, and tolerant to surge voltages up to 250V, this compact module ensures reliable performance in high-demand environments. Exported across India by leading manufacturers, suppliers, and traders.

Application Places & Extra Features

The Mitsubishi BL296PB-08F is engineered for installation in electrical panels, automation facilities, and industrial control centers. Its compact size and screw terminal connectors facilitate easy integration, while the high-grade insulation and copper conductors maximize safety and conductivity. Extra features include humidity tolerance of up to 85% RH and a dielectric strength exceeding 1000V AC, ensuring safe and stable operation even in challenging site conditions. Suitable for demanding automation equipment configurations.

Domestic Market & Delivery Details

Focused on the Indian market, the Mitsubishi BL296PB-08F is available for swift drop-off and reliable freight arrangements. Shipped goods are handled with care by dedicated exporters, manufacturers, suppliers, and traders, providing seamless delivery across states. Typically, delivery time varies based on distance and logistics, with supply ability scaled to meet bulk industrial requirements. The streamlined shipping process ensures timely availability for electrical and automation projects nationwide.

FAQ's of Mitsubishi BL296PB-08F:

Q: How is the Mitsubishi BL296PB-08F relay installed in automation systems?

A: The relay can be easily installed using its DIN rail mount design, making it compatible with standard electrical panels and automation equipment setups.

Q: What are the benefits of using the BL296PB-08F in industrial applications?

A: Its robust build, rapid response time, and long operational life provide reliable switching and control, reducing downtime and maintaining productivity in demanding environments.

Q: When can I expect the Mitsubishi BL296PB-08F to be shipped after placing an order?

A: Delivery time is dependent on your location and supply quantity, with most shipments processed promptly through reliable freight and drop-off networks in India.

Q: Where is the best site of application for the BL296PB-08F?

A: Ideal sites include automation facilities, electrical control panels, and industrial machinery requiring precise and durable relay switching.

Q: What process should be followed for connecting cables to the relay module?

A: Use the screw terminal connectors for secure attachment of suitably sized single-core copper conductors rated for the module's voltage and current specifications.

Q: How can users ensure the Mitsubishi BL296PB-08F operates safely under varying environmental conditions?

A: The relay's IP20 protection, humidity tolerance, and high dielectric strength offer dependable performance; ensure the module is installed within recommended temperature and humidity ranges for optimal safety.
