Mitsubishi QD70D8

Get a Price/Quote

Mitsubishi QD70D8 Specification

Operating Temperature
0C to 55C

Rated Voltage
24 V DC

Input Current
300 mA (Max)

Phase
Single Phase

Efficiency
High

Humidity
5% to 95% RH, Non-condensing

Output Voltage
5 V DC (Output Interface)

Frequency
50/60 Hz

Protection Level
IP20

Mounting Type
DIN Rail Mounting

Main Material
Plastic, Electronics

Processing Type
Digital

Condition
New

Function
High-Speed Pulse Output Positioning Module

Application
MR-J2/J3/J4-B Servo Positioning, Industrial Automation

Dimension (L*W*H)
98 mm 27.4 mm 90 mm

Power Mode
DC Powered

Voltage
24 V DC

Power Consumption
6.2 W

Accessories
User Manual, Mounting Accessories

Module Type
Positioning Module

Isolation
Photocoupler Isolation

Weight
0.23 kg

Product Series
Mitsubishi MELSEC-Q

Number of Axes
8 Axes

Storage Temperature
-25°C to 75°C

Vibration Resistance
5 Hz to 9 Hz, single amplitude 3.5 mm

Pulse Output
200 kpps (Max)

Control Interface
Open Collector/Differential

Display
LED Status Indicators

Compatible CPUs
Q Series PLCs

Shock Resistance
150 m/s², 11 ms, 3 times each in X, Y, Z axis

Update Period
0.5 ms (Min)

Output Type
Differential Line Driver

About Mitsubishi QD70D8

Step into the elite order of industrial automation with the Mitsubishi QD70D8 Positioning Module from the spectacular MELSEC-Q Series. Featuring dazzling 8-axis control, this remarkable module delivers high-speed pulse outputs up to 200 kpps for MR-J2/J3/J4-B Servo systems. Designed for reserve performance and flawless precision, its differential line driver ensures robust connectivity while photic isolation enhances safety. With superior vibration and shock resistance, advanced diagnostics via LED indicators, and IP20 protection, the QD70D8 stands as a premier choice for high-efficiency and resilient positioning in demanding industrial environments.

Extraordinarily Featured Elite Module

The Mitsubishi QD70D8 showcases a dazzling range of extra features including rapid 0.5 ms updates, high-efficiency output, and eight independent axes for exceptional control. Manufactured with select plastic and advanced electronics, it offers remarkable isolation via phototransistors, protecting internal circuits. The module's resilience shines through its resistance to vibration and impact. LED status indicators and a clear user manual bring additional convenience, while easy DIN-rail mounting and IP20 protection elevate its versatility for industrial use.

Spectacular Sample Policy & Fast Dispatch

Experience a seamless ordering process with Mitsubishi QD70D8's sample policy, ensuring that clients can review quality before final outlay. Benefit from quick dispatch and efficient drop-off, reducing downtime in your operations. Our streamlined delivery time means your elite module reaches you promptly in all major domestic markets. Whether you're located in an industrial hub or a regional center, exceptional service and consistency mark every step of the transaction, making us a trusted exporter, manufacturer, supplier, and trader across India.

FAQ's of Mitsubishi QD70D8:

Q: How does the Mitsubishi QD70D8 enhance industrial automation?

A: The QD70D8 provides elite multi-axis control with high-speed pulse outputs, making it ideal for precise servo positioning in automated environments, improving efficiency and process reliability.

Q: What are the main usage scenarios for the Mitsubishi QD70D8 Positioning Module?

A: This module is perfect for MR-J2/J3/J4-B Servo Positioning, complex motion control, and high-speed digital applications in industrial automation systems.

Q: Where can I mount the Mitsubishi QD70D8 in my setup?

A: The QD70D8 is designed for DIN rail mounting, enabling easy installation in standardized industrial control panels.

Q: When can I expect delivery after placing an order for the Mitsubishi QD70D8?

A: With our quick dispatch process, delivery times are minimized. The module is generally shipped promptly to ensure rapid drop-off across India's main domestic markets.

Q: What is the process for requesting a sample of the QD70D8 module?

A: Simply contact our sales team to request a sample. Our sample policy allows you to review product quality before committing to a larger outlay, ensuring your satisfaction.

Q: What are the remarkable protection features of the QD70D8?

A: It offers IP20-rated protection, phototransistor isolation, and resilience to vibration and shock, safeguarding the module and ensuring ongoing operational reliability.

Tell us about your requirement
