Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount
Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount
images Send Inquiry
Request To Call Back
  • Home
  • Products
  • Mitsubishi PLC
  • Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount

Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount

Price 20000.0 INR/ Piece

Get a Price/Quote
MOQ : 1 Piece

Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount Specification

  • Mounting Type
  • Direct horizontal 35mm DIN Rail profile or manual panel surface screw layout
  • Efficiency
  • Execution speeds down to 34 nanoseconds (ns) per basic instruction
  • Output Voltage
  • 24 V DC Volt (V)
  • Humidity
  • 5% to 95% relative humidity matrix parameters (Non-condensing boundaries)
  • Frequency
  • 50 Hertz (HZ)
  • Operating Temperature
  • -20 C to +55 C Celsius (oC)
  • Phase
  • Single-Phase Power Infrastructure Line Loop
  • Input Current
  • Maximum 25 A for 5 ms at 100V AC | Maximum 50 A for 5 ms at 200V AC
  • Protection Level
  • IP20
  • Rated Voltage
  • 100 240 V AC Volt (V)
  • Main Material
  • Usage
  • Advanced Automation
  • Condition
  • New
  • Size
  • 32-point integrated I/O blocks (16 discrete inputs / 16 discrete outputs)
  • Function
  • 32 I/O Logic Central Controller Main Engine
  • Height
  • 9.00 Centimeter (cm)
  • Application
  • High-Speed Centralized Machine Processing Core
  • Product Type
  • MELSEC iQ-F Series Compact Programmable Logic Controller Main Engine
  • Dimension (L*W*H)
  • 8.30 cm x 15.00 cm x 9.00 cm Centimeter (cm)
  • Weight
  • 0.65 Kilograms (kg)
  • Color
  • Industrial Dark Gray Shell / Translucent Terminal Covers
  • Voltage
  • 100 V to 240 V AC Volt (v)
  • Width
  • 15.00 Centimeter (cm)
  • Length
  • 8.30 Centimeter (cm)
  • Power Consumption
  • 30 Watt (W)
  • Accessories
  • Pre-fitted screw terminal blocks and an integrated rail grounding clip
  • Warranty
  • Standard Mitsubishi Electric Factory Warranty


Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Delivery Time
  • 2 Week


About Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount

Orchestrate complex automation arrays with the high-performance Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller. As the flagship main processing unit of the advanced MELSEC iQ-F Series platform, this single-slot controller executes basic logic commands at an ultra-fast 34 ns instruction speed. The onboard hardware layout provides a dense 32-point system core split evenly into 16 digital inputs (24V DC Sink/Source) and 16 robust mechanical relay outputs rated for 2 A per point (240V AC or 30V DC loops). Driven by an wide-range 100240V AC power engine, the unit also features a built-in 24V DC service supply loop capable of sourcing up to 400 mA to power local field sensors directly.
The definitive engineering advantage of this CPU is its exceptional native connectivity and embedded instrumentation features:
  • High-Speed & Memory Engines: Integrates 8 channels of high-speed hardware counting (up to 200 kHz) and a dedicated SD card slot to execute real-time data logging, system backups, and 64k-step program execution via the unified GX Works3 programming suite.
Mitsubishi Electric FX5U-32MR/ES Programmable Logic Controller, embedded Ethernet and RS-485 interfaces, 64k-step flash capacity, IP10 DIN-rail mount
